Fiberglass Specifications:

This semi-displacement hull is solid hand-laid fiberglass of alternate layers of matt and woven roving. Thickness of the hull will vary from 3/8″ to 3/4″ at high rudder port bearings, which require extra thickness. The superstructure is made up of hand-laid fiberglass and utilizes an end grain balsa core for structural rigidity and weight reduction.

Cruising speed for approximately 12,000 lbs. displacement and approximately 300 HP (engine size is owner’s choice), is 17-19 knots. Top speeds are around 20-23 knots.

Specs:

  • Length: 30’9″
  • LWL: 28’11”
  • Beam: 12’0″
  • Draft: 3’3″
  • Displacement: 14,000 lbs.

Typical Configuration:

FUEL SYSTEM

  • 150 gal. (marine grade alum. tanks)
  • Dual Racor fuel filters
  • Port, starboard or “both” fuel valving
  • Port & starboard tanks are self -leveling
  • CG approved fuel hose
  • Fuel gauges

WATER SYSTEM

  • 60 gal. water capacity (poly tanks)
  • Hot & cold pressurized water in Polybutelene tubing, in-line strainers
  • Pressure pump
  • Stainless sinks in galley & head

ENGINE ROOM

  • Engine sizes range from 250 HP to 420 HP
  • SS A-22 shaft
  • Dripless stuffing box
  • Cutlass bearing
  • Bronze or Nibral propeller
  • Vibration dampening engine mounts
  • Sound insulation engine space
  • Lighted engine space (2 lights)
  • White gelcoated engine space
  • Engine compatible exhaust system
  • Raw water strainer

EXTERIOR

  • SS or chrome hardware (2) 10″ stern cleats, (2) 10” spring cleats, bow cleat, skene chocks
  • Aluminum framed windows (choice of opening) with screens and tinted safety glass
  • (4) SS portlights with screens
  • Oiled teak rubrails and toe rails
  • SS half-oval wear strip on rub rails
  • (4) Teak grab rails
  • PVC quarterguards w/SS half oval wear strip
  • Stem iron (half oval stainless steel)
  • Deck pipe for anchor line
  • Sling tags
  • Stainless steel bow rail

ELECTRICAL

  • All marine grade wire and wiring
  • Electrical panel
  • Standard 12V system
  • (2) size 4D marine batteries w/#1, #2 both switch
  • Completely bonded grounding system to a large, master zinc
  • 12 volt lighting for interior, exterior, and engine room

GALLEY

  • Seaward/Princess 2 burner LP gas range
  • Seaward safety shutoff solenoid at LP tank
  • Norcold undercounter refrigerator
  • Ample storage space, shelving and drawers
  • Lighting

FORWARD CABIN AND VEE BERTH

  • Ample storage under berths
  • 5″ foam mattresses w/choices of fabric
  • Individual reading lights
  • Paneled door on hanging locker
  • Bomar ventilating hatch
  • Teak and holly cabin sole

HEAD

  • Stainless steel sink
  • Lavatory cabinet
  • Dome lights
  • Marine toilet
  • Hand held shower
  • SALON/PILOT HOUSE
  • Fiberglass sole
  • Soundproofed overhead
  • Helm console

COCKPIT

  • Molded fiberglass cockpit sole
  • Large lazarette access hatch
  • Deckplate for emergency steering arm

SAFETY

  • (2) Hand-held fire extinguishers
  • (2) Bilge pumps Fwd & Aft compartment
  • Non-skid on exterior walking surfaces

GENERAL NOTES

  • Options include a flying bridge, air conditioning,
  • windlass, generator, and bow thruster.
  • Layout, equipment, choice of woods,
  • and finish are up to the owner.
  • Every boat is unique.
