Fiberglass Specifications:

This semi-displacement hull is solid hand-laid fiberglass of alternate layers of matt and woven roving. Thickness of the hull will vary from 3/8″ to 1 1/2″ at high rudder port bearings, which require extra thickness. The superstructure is made up of hand-laid fiberglass and utilizes an end grain balsa core for structural rigidity and weight reduction.

Specs:

  • LOA: 61′
  • LWL: 54′-2″
  • Beam: 17′
  • Draft: 5’–2″
  • Displacement: 75,000 lbs
  • Cruising Speed: 21 knots
  • Max Speed: 25 knots



Typical Configuration:

FUEL SYSTEM

  • 1000 gal.
  • Racor fuel filters
  • Port, starboard or “both” fuel valving
  • Port & starboard tanks are self -leveling
  • CG approved fuel hose
  • Fuel gauges

WATER SYSTEM

  • 300 gal. water capacity
  • Hot & cold pressurized water in Polybutelene tubing, in-line strainers
  • Pressure pump
  • Stainless sinks in galley & heads

ENGINE ROOM

  • Engine make and size are owner’s option
  • SS A-22 shaft
  • Dripless stuffing boxes
  • Stainless steel struts and rudders
  • Nibral propellers
  • Vibration dampening engine mounts
  • Sound insulated engine space
  • Well lit engine space
  • White gelcoated engine space
  • Engines spray painted white
  • Engine compatible exhaust system
  • Raw water strainers
  • Marine Mufflers and underwater exhaust
  • Hydraulic steering system
  • Kobelt controls

EXTERIOR

  • SS or chrome hardware (4) 10″ cleats, bow bit, skene chocks
  • Aluminum framed windows (choice of opening) with screens and tinted safety glass
  • (6) SS portlights with screens
  • Rub rails and toe rails
  • SS half-oval wear strip on rub rails
  • Ample handholds and grab rails
  • Molded quarterguard w/SS half oval wear strip
  • Stem iron (half oval stainless steel)
  • Deck pipe for anchor line
  • Sling tags
  • Stainless steel bow rail

ELECTRICAL

  • All marine grade wire and wiring
  • Backlit electrical panels
  • Standard 12V system
  • Battery banks to meet system requirements
  • Completely bonded grounding system to a large, master zinc
  • 110 VAC dockside power with outlets
  • Generator
  • Battery Charger

GALLEY

  • Seaward/Princess LP gas stove w/oven
  • Seaward safety shutoff solenoid at LP tank
  • Full size refrigerator / freezer
  • Ample storage space, shelving and drawers
  • Lighting
